1. 6.0V-8.4V High voltage.High performance digital High Voltage Brushless.
2. Waterproof performance: IP67.
3. Precision metal steering gear.
4. Widely Use Digital Servo:The steering servo (Control Angle 180°) Compatible with 1/5, Scale Clawer Truck, Traxxas,
RC Car / Robot / Boat and other remote control models.
Description:
100KG Large torque Digital Waterproof servo,adopt Brushless motor,Compared with ordinary servo, the speed is much faster and the
reaction is also fast,6.0V ~8.4V High Operation Voltage Range,
It's a good accessory for your RC RC Car Truck Crawler Boat Robot and DIY model toy!
Specifications:
Brand: GXservo
Model: X100
Puise Width: 500μs-2500μs =180°/270°/360°
Operating Speed: (6.0V)0.16sec60°
Operating Speed: (7.4V)0.14sec60°
Operating Speed: (8.4V)0.13sec60°
Stall Torque(6.0V): 92kg.cm
Stall Torque(7.4V): 100kg.cm
Stall Torque(8.4V): 110kg.cm
Operating Voltage: 6.0V-8.4V
Gear Type: Steel
Motor: Brushless motor
Dead band: 2μs
Ball Bearing: 3BB
Working Frequence: 1520μs/330hz
Shell Materal: CNC aviation aluminium alloy
spline tooth? 15T
Control System: Customizable(PWM,RS485 ,TTL,CAN)
Dimensions: 65*30*58mm
Weight: 210g
![](https://ae01.alicdn.com/kf/S1162e45e384048f1b06858a0d263154d8.jpg)
![](https://ae01.alicdn.com/kf/S2a3ecc412987480db51c80a9c71f0bb6i.jpg)
![](https://ae01.alicdn.com/kf/Sdc4eed9a163148bf8e697ae5f48c9a86l.jpg)
![](https://ae01.alicdn.com/kf/Se0d2fdec82164444bf8c31b618090ae9b.jpg)
![](https://ae01.alicdn.com/kf/Sd6a0c608995a4653a5da71230c11c3c6n.jpg)
![](https://ae01.alicdn.com/kf/Sa919d6d1fdeb447d8c244660cd56482fn.jpg)
![](https://ae01.alicdn.com/kf/S58326866e25241e79c5f30894342f7c1U.jpg)
![](https://ae01.alicdn.com/kf/S9cd9006d884c433eb739c7b598bad9f87.jpg)
![](https://ae01.alicdn.com/kf/Sb6a9cbef2c0b49e1bf99c1a91aa5ab81D.jpg)
![](https://ae01.alicdn.com/kf/S133356fece2845cd8ec8c23fefb044caC.jpg)
![](https://ae01.alicdn.com/kf/Sde9d181317654c189dc984f6fd9595e6v.jpg)
Specifications
Quantity
1 pcs
Model Number
X100
Remote Control Peripherals/Devices
Servos
RC Parts & Accs
Servos
Material
Metal
Brand Name
GXservo
Origin
Mainland China
Recommend Age
12+y,18+
Use
Vehicles & Remote Control Toys
